Doze pick-up Audio-Technica

Noua gama Audio-Technica - dual moving-magnet

Ac MicroLine (2.5 x 75 um) - masiv ( Nude Shank ) / suspensie din Al

• Montura: 1/2"
• Tensiune de Iesire: 4 mV
• Raspuns in frecventa: 20 Hz - 27 kHz
• Separatie intre Canale: 28 dB

• Liniaritate: 1 dB
• Compliance: 40 / 10 - S / D (x10-6 cm/dyne)
• Greutate: 8 gr

• Testeaza in showroom Cotroceni

Noua gama Audio-Technica entry-level

Ac eliptic ( 7.6 x 17.8 microni ) - lipit ( Bonded Shank ) / suspensie din Al

Fabricat in China

• Montura: 1/2"
• Tensiune de Iesire: 4 mV
• Raspuns in frecventa: 20 Hz - 20 kHz
• Separatie intre Canale: 20 dB

• Liniaritate: 2.0 dB
• Compliance: 17 / 7 - S / D (x10-6 cm/dyne)
• Greutate: 6.1 gr

• Testeaza in showroom Cotroceni

Noua gama Audio-Technica - dual moving-magnet

Ac MicroLine (2.5 x 75 um) - masiv ( Nude Shank ) / suspensie din Al

• Montura: 1/2"
• Tensiune de Iesire: 4 mV
• Raspuns in frecventa: 20 Hz - 27 kHz
• Separatie intre Canale: 28 dB

• Liniaritate: 1 dB
• Compliance: 40 / 10 - S / D (x10-6 cm/dyne)
• Greutate: 6.4 gr

Noua gama Audio-Technica entry-level

Ac conic ( 15.25 microni ) - lipit ( Bonded Shank ) / suspensie din Al

Fabricat in China

• Montura: 1/2"
• Tensiune de Iesire: 4 mV
• Raspuns in frecventa: 20 Hz - 20 kHz
• Separatie intre Canale: 18 dB

• Liniaritate: 2.5 dB
• Compliance: 17 / 6.5 - S / D (x10-6 cm/dyne)
• Greutate: 6.1 gr

Noua gama Audio-Technica entry-level

Ac MicroLine (2.5 x 75 um) - masiv ( Rounded Nude Shank ) / suspensie din Al

Fabricata in Japonia

• Montura: 1/2"
• Tensiune de Iesire: 3.5 mV
• Raspuns in frecventa: 20 Hz - 25 kHz
• Separatie intre Canale: 23 dB

• Liniaritate: 1.5 dB
• Compliance: 20 / 10 - S / D (x10-6 cm/dyne)
• Greutate: 6.1 gr

Doza Moving-Magnet cu ac conic ( 15.25 microni ) - Bonded Round Shank

• Montura: P-mount
• Tensiune de Iesire: 3.5 mV
• Raspuns in frecventa: 20 Hz - 20 kHz
• Separatie intre Canale: 18 dB

• Liniaritate: 2.5 dB
• Compliance: nc
• Greutate: nc

Noua gama Audio-Technica entry-level

Ac eliptic ( 7.6 x 17.8 microni ) - masiv ( Rounded Nude Shank ) / suspensie din Al

Fabricat in Japonia

• Montura: 1/2"
• Tensiune de Iesire: 3.5 mV
• Raspuns in frecventa: 20 Hz - 23 kHz
• Separatie intre Canale: 22 dB

• Liniaritate: 2.0 dB
• Compliance: 20 / 7 - S / D (x10-6 cm/dyne)
• Greutate: 6.1 gr

Noua gama Audio-Technica - dual moving-magnet
Ac Shibata (5 x 92 um) - masiv ( Nude Shank ) / suspensie din Al

• Montura: 1/2"
• Tensiune de Iesire: 4 mV
• Raspuns in frecventa: 20 Hz - 27 kHz
• Separatie intre Canale: 30 dB

• Liniaritate: 1 dB
• Compliance: 40 / 10 - S / D (x10-6 cm/dyne)
• Greutate: 8 gr

Doza DJ Hi-Fi cu ac conic ( 15 um ) - Bonded Round Shank

• Montura: 1/2"
• Tensiune de Iesire: 5.5 mV
• Raspuns in frecventa: 20 Hz - 18 kHz
• Separatie intre Canale: 20 dB

• Liniaritate: 2.0 dB
• Compliance: 20 / 6 - S / D (x10-6 cm/dyne)
• Greutate: 6.2 gr

Doza Moving-Magnet cu ac eliptic ( 7.6 x 17.8 microni ) - Bonded Round Shank


Fabricat in Japonia

• Montura: P-mount
• Tensiune de Iesire: 3.5 mV
• Raspuns in frecventa: 20 Hz - 20 kHz
• Separatie intre Canale: 20 dB

• Liniaritate: 2 dB
• Compliance: nc
• Greutate: nc

Noua gama Audio-Technica - dual moving-magnet

Ac eliptic ( 7.6 x 17.8 um) - masiv ( Nude Shank ) / suspensie din Al

• Montura: 1/2"
• Tensiune de Iesire: 4 mV
• Raspuns in frecventa: 20 Hz - 25 kHz
• Separatie intre Canale: 27 dB

• Liniaritate: 1.5 dB
• Compliance: 35 / 8 - S / D (x10-6 cm/dyne)
• Greutate: 6.4 gr

Noua gama Audio-Technica entry-level

Ac conic ( 75 microni ) - lipit ( Bonded Shank ) / suspensie din Al

Special destinat discurilor Shellac 78 rpm

Fabricat in Japonia

• Montura: 1/2"
• Tensiune de Iesire: 2.7 mV
• Raspuns in frecventa: 20 Hz - 20 kHz
• Separatie intre Canale: 18 dB

• Liniaritate: 2.5 dB
• Compliance: 12 / 2 - S / D (x10-6 cm/dyne)
• Greutate: 6.1 gr

Noua gama Audio-Technica - dual moving-magnet

Ac conic ( 15.25 microni ) - lipit ( Bonded Shank ) / suspensie din Al

• Montura: 1/2"
• Tensiune de Iesire: 5 mV
• Raspuns in frecventa: 20 Hz - 20 kHz
• Separatie intre Canale: 25 dB

• Liniaritate: 1.5 dB
• Compliance: 35 / 8 - S / D (x10-6 cm/dyne)
• Greutate: 6.4 gr

Doza DJ Hi-Fi cu ac Eliptic ( 7.6 x 17.8 um ) - Bonded Round Shank

• Montura: 1/2"
• Tensiune de Iesire: 5.5 mV
• Raspuns in frecventa: 20 Hz - 18 kHz
• Separatie intre Canale: 20 dB

• Liniaritate: 2.0 dB
• Compliance: 20 / 6 - S / D (x10-6 cm/dyne)
• Greutate: 6.2 gr

Doza Moving-Coil cu ac MicroLine ( 2.5 x 75 microni ) - Nude Square Shank



Fabricat in Japonia

• Montura: 1/2"
• Tensiune de Iesire: 0.3 mV
• Raspuns in frecventa: 15 Hz - 50 kHz
• Separatie intre Canale: 30 dB

• Liniaritate: 0.5 dB
• Compliance: 40 / 10 - S / D (x10-6 cm/dyne)
• Greutate: 6.9 gr

Doza Moving-Coil cu ac Special Line Contact ( 38 x 7 um ) - Nude Square Shank

Fabricat in Japonia

• Montura: 1/2"
• Tensiune de Iesire: 0.4 mV
• Raspuns in frecventa: 20 Hz - 50 kHz
• Separatie intre Canale: 28 dB

• Liniaritate: 0.5 dB
• Compliance: 22 / 18 - S / D (x10-6 cm/dyne @100Hz)
• Greutate: 7.6 gr

Doza Moving-Coil cu ac Shibata ( 5 x 75 microni ) - Nude Square Shank


Fabricat in Japonia

• Montura: 1/2"
• Tensiune de Iesire: 0.4 mV
• Raspuns in frecventa: 15 Hz - 50 kHz
• Separatie intre Canale: 30 dB

• Liniaritate: 0.5 dB
• Compliance: 40 / 10 - S / D (x10-6 cm/dyne)
• Greutate: 6.9 gr

ac Special Line Contact
suspensie din boron 0.28mm diametru

• Montura: 1/2"
• Tensiune de Iesire: 0.5 mV
• Raspuns in frecventa: 20 Hz - 50 kHz
• Separatie intre Canale: 30 dB

• Liniaritate: 0.5 dB
• Compliance: 25 / 15 - S / D (x10-6 cm/dyne)
• Greutate: 8.5 gr

Doza Moving-Coil cu ac Eliptic ( 7 x 18 um ) - Round Bonded Shank

Fabricat in Japonia

• Montura: 1/2"
• Tensiune de Iesire: 0.32 mV
• Raspuns in frecventa: 20 Hz - 30 kHz
• Separatie intre Canale: 25 dB

• Liniaritate: 1.5 dB
• Compliance: 20 / 9 - S / D (x10-6 cm/dyne)
• Greutate: 7.6 gr

Noua gama Audio-Technica - dual moving-magnet
Ac Super Line Contact - masiv ( Nude Shank ) / suspensie din Al

• Montura: 1/2"
• Tensiune de Iesire: 4 mV
• Raspuns in frecventa: 20 Hz - 30 kHz
• Separatie intre Canale: 30 dB

• Liniaritate: 1 dB
• Compliance: 40 / 10 - S / D (x10-6 cm/dyne)
• Greutate: 8 gr
