Boxe Tip: Boxe perete/tavan

Boxa incastrabila in tavan, 2 cai
tweeter 2.5 cm Diamond Dome Nautilus tube-loaded
mid/bas 18 cm Continuum dome w. antiresonance plug
Raspuns in frecventa : 35 Hz – 35 kHz
Sensibilitate : 88 dB ( 2.83V @ 1 m )
Impedanta nominala: 8 ohm
Amplificare recomandata: 120 W
dimensiuni decupaj - 331 x 331 mm
adancime montaj - 166 mm

Boxa incastrabila in tavan, 2 cai, adancime redusa
Difuzoare :
tweeter - 2.5 cm Nautilus™ swirl loaded aluminium dome ( TILT + EQ )
mid/bs - 15 cm blue Aramid Fibre cone
Raspuns in frecventa : 45 Hz – 50 kHz
Sensibilitate : 86 dB
Impedanta nominala: 8 ohm
Amplificare recomandata: 25 - 100 W
dimensiuni decupaj - 202 mm
adancime montaj - 92 mm

Prin array-ul coaxial Uni-Q ce ofera o dispersie superioara si un sunet natural, boxele KEF Ci160QS reprezinta solutia ideala pentru montajul la fata cu tavanul.

Boxa incastrabila in tavan, 2 cai
Difuzoare : 1 tweeter 1.9 cm + 1 x mid-woofer 16cm
Raspuns in frecventa : 38Hz – 34 kHz
Sensibilitate : 89dB ( 2.83V @ 1 m )
Impedanta nominala: 8 ohm
Amplificare recomandata: 10 - 125W

Boxa incastrabila in perete, 2 cai
Difuzoare : 1 tweeter 2.5 cm + 2 x mid-woofer 10 cm
Raspuns in frecventa : 60 Hz – 25 kHz
Sensibilitate : 88 dB ( 2.83V @ 1 m )
Impedanta nominala: 6 ohm
Amplificare recomandata: 20 - 100 W

Boxa incastrabila in perete, 2 cai
Difuzoare : 1 tweeter 2.5 cm + 1 x mid-woofer 13 cm
Raspuns in frecventa : 75 Hz – 25 kHz
Sensibilitate : 85 dB ( 2.83V @ 1 m )
Impedanta nominala: 6 ohm
Amplificare recomandata: 20 - 50 W

Prin array-ul coaxial Uni-Q ce ofera o dispersie superioara si un sunet natural, boxele KEF Ci160.CR reprezinta solutia ideala mai ales datorita inaltimii mici de instalare

Boxa incastrabila in tavan, 2 cai
Difuzoare : 1 tweeter 1.6 cm + 1 x mid-woofer 16 cm
Raspuns in frecventa : 52Hz – 20 kHz
Sensibilitate : 89 dB ( 2.83V @ 1 m )
Impedanta nominala: 8 ohm
Amplificare recomandata: 10 - 100 W

Boxa incastrabila in perete, 2 cai
Difuzoare : 1 tweeter 2.5 cm + 2 x mid-woofer 10 cm
Raspuns in frecventa : 60 Hz – 25 kHz
Sensibilitate : 88 dB ( 2.83V @ 1 m )
Impedanta nominala: 6 ohm
Amplificare recomandata: 20 - 100 W

2 x Difuzor inalte 1"
Woofer 8"
Putere recomandata: 50 - 125 W
Raspuns in frecventa: 38Hz - 20kHz

Boxa incastrabila in perete, 3 cai
Difuzoare : 1 tweeter 2.5 cm + 1 x mid 10 cm + 1 x woofer 20 cm
Raspuns in frecventa : 50 Hz – 30 kHz
Sensibilitate : 89 dB ( 2.83V @ 1 m )
Impedanta nominala: 6 ohm
Amplificare recomandata: 30 - 120 W

Boxa incastrabila in perete, 2 cai
Difuzoare : 1 tweeter 2.5 cm + 1 x mid-woofer 20 cm
Raspuns in frecventa : 50 Hz – 25 kHz
Sensibilitate : 89 dB ( 2.83V @ 1 m )
Impedanta nominala: 6 ohm
Amplificare recomandata: 30 - 120 W

Boxa incastrabila in perete, 2 cai
Difuzoare : 1 tweeter 2.5 cm + 1 x mid-woofer 15 cm
Raspuns in frecventa : 65 Hz – 25 kHz
Sensibilitate : 88 dB ( 2.83V @ 1 m )
Impedanta nominala: 6 ohm
Amplificare recomandata: 20 - 65 W

Tweeter: 1" (25mm) Al/Mg inverted dome
Medii: 4" (10cm) Flax
Woofer: 2 x 5" (13cm) Flax
Raspuns in frecventa: 55Hz - 28kHz
Putere recomandata: 50 - 150W

1x Ø25mm (1 in) soft dome tweeter
1x Ø150mm (6 in) polypropylene
cone bass/midrange

THX® Certified Ultra
Mounting Depth From Surface: 99mm
Wall Thickness (Maximum): 40mm (1.58in.)
Wall Thickness (Minimum): 6mm
Max SPL (dB): 110dB

2-way system
1x Ø25mm (1 in) soft dome tweeter
1x Ø200mm (8 in) polypropylene
cone bass/midrange

Ci3120QLM-THX beneficiaza si de o alta inovatie acustica revolutionara: Metamaterial Absorption Technology (MAT). MAT este o structura complexa, labirintica, care absoarbe 99% din sunetele nedorite provenite din spatele tweeter-ului, oferind o redare mai clara si mai naturala a frecventelor inalte.

Difuzor inalte: 16mm
Difuozr joase: 200mm
Imepdanta nominala: 8 Ohms
Raspuns in frecventa: 45Hz - 20kHz (±6dB) open-backed
Sensibilitate: 90dB
Putere recomandata: 10-125W

THX® Certified Ultra
Mounting Depth From Surface: 99mm
Wall Thickness (Maximum): 40mm (1.58in.)
Wall Thickness (Minimum): 6mm
Max SPL (dB): 110dB

Ci3160REFM-THX oferă un bas curat, bogat și foarte articulat, datorită celor două drivere de frecvente joase de 160 mm (6,5 inchi). Proiectat special pentru un spatiu inchis, incastrat, driverele sale sunt foarte puternice, au un sistem de ventilare eficient si gestioneaza nivele impresionante de putere. Proiectarea extrem de inteligenta face acest model sa dispara practic in spatiul dvs si sa ofere o experienta intensa, plina de impact si realism.
- adancime instalare de la suprafata peretului 99mm
- grosime maxima perete 40mm
- grosime minima perete 6mm
